Robot wars: mining supremacy is a matter of deploying robotics effectively
Robotics has led to optimised travel and operations, as well as automation on mine sites.
Any successful mining company is already using robotics; the competitive edge belongs to those who use robotics better.
For example, Fortescue implemented robotics for 43% pit-to-port savings; Rio Tinto’s autonomous train saves almost 1.5 million kilometres of annual road travel, and Boliden’s automated drill rigs are capable of 40% more operating hours than conventional alternatives.
Fortescue Metals Group
Fortescue Metals Group deployed a fleet of autonomous trucks at its Solomon Hub mines. The company began deploying Caterpillar autonomous trucks in 2012, at the Firetail and Kings Valley iron ore mines. The deployment was successful — the trucks at the initial two mines have moved over 200 million tons of material since 2012 — and Fortescue has expanded its fleet to other projects.
Pit-to-port costs at the Solomon Hub mines decreased by 43% with the implementation of the trucks. The gains come from a combination of higher productivity and lower expenses.
Rio Tinto’s iron ore business operates the world’s first fully autonomous heavy-haul long-distance railway. AutoHaul operates in the Pilbara region of Western Australia. The network involves 200 locomotives and 1,700km of track. Each train comprises three locomotives and carries 28,000t of ore.
Trains are monitored remotely from an operations centre over 1,500km away, and tThe operations team uses simulations, tests, and data from real runs to optimise the project. AutoHaul began full operations in 2019.
AutoHaul precludes the need to transport drivers to and from trains, saving around 1.5 million kilometres of road travel each year. Safety is improved by reducing personnel, and because AutoHaul performs better than human drivers at level crossings and has automated responses to speed restrictions and alarms.
It also provides environmental gains by calculating the most consistent driving strategy from the train and network topography data, which involves as little accelerating and decelerating as possible.
Boliden’s Aitik mine uses automated drilling rigs for its drilling and blasting operations. Such operations require much precision — the distance between each drill hole must be exact — and the material transfer chain is quite delicate. Though the task is difficult, it is repetitive, which made it ripe for automation.
The automated rigs that were introduced, known as ‘pit vipers’, can move between drill holes autonomously. Predefined tasks can be performed autonomously, and undefined tasks can be performed remotely using the cameras attached.
Five drills at Aitik have been upgraded to pit vipers. Automation increases annual operating hours, on average, by 40%, from 5,000 to 7,000.
// Main image:Trains carrying ore. Credit: Productaction via Shutterstock
